Developing Advanced Eclipse XMF Applications

case LibraryTest {

  // Define system states that will be used in the
  // test scripts....

  state hasBook(n)->(b) {

    // State hasBook is satisfied when the
    // current library state contains a book
    // b with the title n. The state receives
    // the name n and returns the book b...

    obj(root,library.Library) {
      books contains b;
    }

    obj(b,library.Book) {
      title = n;
    }
  }

  ->

  let () = match hasBook("Pride and Prejudice")
  in
      // If there is a book with the supplied title then
      // raise an error...

      raise bookExists("Not expecting a book.");

  else {
    // Do nothing...
  }
}

obj(var,class) {
  slotName = slotValue;
  slotName contains slotValue;
  ...
}

case LibraryTest {

  // Define system states that will be used in the
  // test scripts....

  state hasBook(n)->(b) {

    // State hasBook is satisfied when the
    // current library state contains a book
    // b with the title n. The state receives
    // the name n and returns the book b...

    obj(root,library.Library) {
      books contains b;
    }

    obj(b,library.Book) {
      title = n;
    }
  }

  state hasCopy(book,id) -> (copy) {

    // State hasCopy is satisfied when the
    // current library state has a book with
    // the supplied id. the state returns the
    // copy...

    obj(root,library.Library) {
      books contains book;
      copies contains copy;
    }

    obj(copy,library.Copy) {
      id = id;
      book = book;
    }
  }

  state hasReader(name) -> (reader) {

    // State hasReader is satisfied when the
    // current library state has a reader with
    // the supplied name. The reader is
    // returned...

    obj(root,library.Library) {
      readers contains reader;
    }

    obj(reader,library.Reader) {
      name = name;
    }
  }

  state borrows(reader,copy) -> () {

    // State borrows is satisfied when the
    // current library state records a borrowing
    // event between the supplied reader and the
    // supplied book copy. Nothing is returned...

    obj(root,library.Library) {
      borrowings contains b;
    }

    obj(b,library.Borrows) {
      reader = reader;
      copy = copy;
    }
  }

  ->

  // The following test script is perfomed with respect
  // to the declared system states above...

  // Firstly, check that there is no book in the
  // library with the supplied title...

  let () = match hasBook("Pride and Prejudice")
  in
      // If there is a book with the supplied title then
      // raise an error...

      raise bookExists("Not expecting a book.");
  else {

    // Perform the system action that adds a book
    // with the given title...

    do addBook("Pride and Prejudice");

    // Now use the same state check to ensure that
    // the library state has been updated correctly...

    let (book) = match hasBook("Pride and Prejudice")
    in {

      // If we get here then the library is OK.
      // Now add a copy of the book...

      do addCopy("Pride and Prejudice","copy1");

      // Check that the library has recorded the copy...

      let (copy) = match hasCopy(book,"copy1")
      in {

        // If we get here then the library has correctly
        // recorded the copy of the book. Now add a reader
        // with the given name...

        do addReader("fred");

        // Check that the reader was added...

        let (reader) = match hasReader("fred")
        in {

          // If we get here then the library has a copy of
          // the book and the reader is registered. Record
          // the reader borrowing the book from the library...

          do borrow("fred","copy1");

          // Check that the borrowing has taken place...

          let () = match borrows(reader,copy)
          in {

            // If we get here then everything has gone OK and
            // we do nothing...
          }

          // The borrowing event was not recorded...

          else raise noBorrow("fred","copy1");
        }

        // The reader was not registered...

        else raise readerNotCreated("fred");
      }

      // A copy of the book was not recorded...

      else raise noCopy("copy1");
    }

    // No book was added to the library...

    else raise noBook("Pride and Prejudice.");
  }
}

@Service newTestSuite(testModel)
  let name = xmf.getString("Name","Name of new Test Suite","")
  in testModel.testSuites.add(TestSuite(name))
  end
end;

@Service loadTestCase(testSuite)

  // Use a try to catch any parsing errors that
  // might be raised and then use a dialog to report
  // the error...

  try
    testSuite.loadTestCase(xmf.openFile(".","*.txt",""))
  catch(x)
    xmf.reportError(x.message)
  end
end;

@Service perform(testCase,library)
  testCase.perform(library)
end;

@Service report(report)
  xmf.browser("Report",report.report())
end;


   <extension point="org.eclipse.ui.popupMenus">
     <objectContribution id="id" objectClass="testing.TestModel">
       <action id="newTestSuite" label="New Test Suite" menubarPath="additions" class="actions.HandleAction" enablesFor="1">
       </action>
     </objectContribution>
   </extension>

   <extension point="org.eclipse.ui.popupMenus">
     <objectContribution id="id" objectClass="testing.TestSuite">
       <action id="loadTestCase" label="Load Test Case" menubarPath="additions" class="actions.HandleAction" enablesFor="1">
       </action>
     </objectContribution>
   </extension>

   <extension point="org.eclipse.ui.popupMenus">
     <objectContribution id="id" objectClass="testing.TestCase">
       <action id="perform" label="Perform" menubarPath="additions" class="actions.HandleAction" enablesFor="1">
       </action>
     </objectContribution>
   </extension>

   <extension point="org.eclipse.ui.popupMenus">
     <objectContribution id="id" objectClass="reports.Report">
       <action id="report" label="Report" menubarPath="additions" class="actions.HandleAction" enablesFor="1">
       </action>
     </objectContribution>
   </extension>


public void run(IAction action) {

  XMFMachine machine = XMFMachineRegistry.getMachine("testing.machine");

  String id = action.getId();
  Object o = selection.getFirstElement();
  ClassLoader loader = classLoader();

  if (id.equals("newTestSuite"))
    machine.sendService("newTestSuite", new Object[] { o },loader);

  else if (id.equals("loadTestCase"))
    machine.sendService("loadTestCase", new Object[] { o },loader);

  else if (id.equals("perform")) {
    Library library = LibraryFactoryImpl.eINSTANCE.createLibrary();
    machine.sendService("perform", new Object[] { o, library },loader);

  } else if (id.equals("report"))
    machine.sendService("report", new Object[] { o },loader);

  else System.out.println("Unknown action id: " + id);
}


context TestSuite
  @Operation loadTestCase(path:String)

    // Use the Grammar::parseFile operation to parse the contents
    // of the file, starting at the non-terminal TestCase...

    self.getTestCases().add(TestCase.grammar.parseFile(path,"TestCase",Seq{}))
  end

@Grammar extends State.grammar

      TestCase ::=

        // A test case is named...

        'case' n = Name '{'

           // has a sequence of state patterns...

           S = State*
           '->'

           // a test script action...

           a = Action
        '}'

      {   // Create the test script...

          let t = TestCase(n,a)
          in
             // Add the states into the script...

             @For s in S do
               t.getStates().add(s)
             end;
             t
          end
      }.

      Action ::=

        // An action is one of...

        Do        // Call an SUT function...
      | Block     // Perform a sequence of actions...
      | Let       // Bind some variables...
      | Raise.    // Raise an exception.

      Condition ::= Str.

      Do ::=

        // Perform a named SUT function...

        'do' n = Name A = LetArgs ';' {

        // Create the Do...

        let d = Do(n)
        in
           // Add in the argument values...

           @For a in A do
             d.getArgs().add(a)
           end;
           d
        end
      }.

      Block ::=

        // A block is a sequence of actions...

        '{' as = Action* '}'

        // Create the block an add in the actions...

         { let b = Block()
           in @For a in as do
                b.getActions().add(a)
              end;
              b
           end
      }.

      Let ::=

        // All types of let-action bind 0 or more
        // arguments. the let-actions differ in terms
        // of where the variable values some from...

        'let' V = LetVars '=' LetBind^(V).

      LetBind(V) ::=

        // Either a state match or an SUT function...

        MatchingLet^(V)
      | DoingLet^(V).

      MatchingLet(V) ::=

        // Name the state pattern and supply any input
        // values..

        'match'

          n = Name

          A = LetArgs

        // Specify the action to perform when the
        // match is successful...

        'in' a = Action

        // Specify the action to perform when the
        // match fails...

        'else' b = Action

      {
        // Create the matching-let and populate the
        // apropriate parts...

        let l = MatchingLet(n,a,b)
        in @For v in V do
             l.getBindings().add(v)
           end;
           @For a in A do
             l.getArgs().add(a)
           end;
           l
        end
      }.

      DoingLet(V) ::=

        // Name the SUT function and supply the values...

        'do' n = Name A = LetArgs

        // Perform a body for the variables...

        'in' a = Action {

        // Create the let and populate it...

        let l = DoingLet(n,a)
        in @For v in V do
             l.getBindings().add(v)
           end;
           @For a in A do
             l.getArgs().add(a)
           end;
           l
        end
      }.

      LetVars ::= '(' LetVarsTail.

      LetVarsTail ::=
        n = Name ns = (',' Name)* ')' { Seq{n|ns}->collect(n | LetVar(n)) }
      | ')' { Seq{} }.

      LetArgs ::= '(' LetArgsTail.

      LetArgsTail ::=
        a = LetArg as = (',' LetArg)* ')' { Seq{a|as} }
      | ')' { Seq{} }.

      LetArg ::= LetVarRef | LetConst.

      LetVarRef ::= n = Name { LetVarRef(n) }.

      LetConst ::= LetInt | LetStr.

      LetInt ::= i = Int { LetInt(i) }.

      LetStr ::= s = Str { LetStr(s) }.

      Raise ::= 'raise' n = Name A = LetArgs ';' {
        let r = Raise(n)
        in @For a in A do
             r.getArgs().add(a)
           end;
           r
        end
      }.

    end

@Operation perform(state)

   // This is the entry point from the service...

   self.perform(Seq{},state)
end

@Operation perform(env,state)

  // Supplied with the variable environment and the SUT
  // state. Create a new report, create a state environment
  // then call the root action with the arguments...

  let report = Report(name,Date())
  in self.getReports().add(report);
     action.perform(env,self.stateEnv(),state,report,
       @Operation(varEnv,state)
          varEnv
        end)
  end
end

@Operation stateEnv()

  // Calculate a state environment...

  states.asSeq()->iterate(s e = Seq{} | e.bind(s.getName(),s))
end
